English | 51

You can use the fine adjustment screw (19) to align vertical laser lines precisely with ref-

erence points.

Place the measuring tool with the guide groove(7) on the guide rail(17) of the rotating

mount(18) and slide the measuring tool all the way onto the platform.

To disconnect the measuring tool, pull it off the rotating mount in the opposite direction.

Positioning possibilities of the rotating mount:

– Standing on a flat surface,

– Screwed to a vertical surface,

– On metallic surfaces using the magnets(20),

– On crown moulding using the ceiling clip(21).

u Keep your fingers away from the rear side of the magnetic accessory while at-

taching the accessory to surfaces. The strong pulling force of the magnets may jam

your fingers.

Roughly align the rotating mount(18) before switching on the measuring tool.

Working with the Laser Target Plate

The laser target plate(24) improves visibility of the laser beam in unfavourable condi-

tions and at greater distances.

The reflective surface of the laser target plate(24) improves visibility of the laser line.

The transparent surface enables the laser line to be seen from behind the laser target

plate.

Working with the Tripod

A tripod offers a stable, height-adjustable support surface for measuring. Place the

measuring tool with the 1/4" tripod mount (6) on the thread of the tripod (27) or a con-

ventional camera tripod. Tighten the measuring tool using the locking screw of the tri-

pod.

Roughly align the tripod before switching on the measuring tool.

Attaching with the Universal Holder (seefigureJ)

You can secure the measuring tool, for example, on vertical surfaces or magnetisable ma-

terials using the universal holder(22). The universal holder is also suitable for use as a

floor stand and facilitates the height adjustment of the measuring tool.

u Keep your fingers away from the rear side of the magnetic accessory while at-

taching the accessory to surfaces. The strong pulling force of the magnets may jam

your fingers.

Roughly align the universal holder(22) before switching on the measuring tool.

Bosch Power Tools 1 609 92A 9B1 | (14.08.2024)
