IR-Receive:When this setting is turned OFF, the camera will not receive signals from the infrared remote controller. Ensure this setting is turned ON for the

camera to communicate with the infrared remote controller.

Comm Type:Describes communication type.

Baud Rate:The rate of data transfer, measured in bits per second.

Display Info:When this setting is enabled, a message displaying the camera’s conguration will appear on the screen for approximately 10 seconds each time the

camera is powered on or restarted.

Video Parameters OSD:Video parameters on screen display.

Tally Mode:When you enable the tally mode, the camera’s tally light will activate. If you’ve connected the camera to a Bolin keyboard controller, you can adjust the

GPI I/O to Output mode in the Keyboard Settings. This allows you to control the tally directly from the keyboard.

Color Space:Option to change color space from YUV 4:2:2 to RGB.

Factory Reset:Resetting all the above settings to factory default.



AUDIO SETTING - AUDIO

In the Audio tab, users can congure the audio settings on the camera to meet their requirements. The various settings and their functions are described below.



Audio Input:Option to Mute audio.

Audio Input Type:Supports Line in voltage only.

Audio Compression:Supports AAC, G.711a and G.711u.

Bit Rate(bps):Supports 32K, 40K, 48K, 64K, 96K, and 128K.

Sampling Rate(sps):Supports 16KHz, 32KHz, 44.1KHz, and 48KHz.

Input Volume:Supports -60db to 18dB.

Phantom Power:Phantom power is a method that provides DC electric power at 48 volts, to sensitive microphones through an XLR cable, eliminating the need

for an external power supply or battery.

CAUTION



Please verify that the microphone in use specically requires 48v of power.

Network Setting - Network

Network
