quit the Trace Memory mode or the PTZ movement is triggered manually.
• RECORD: Record operations.
• MEMORY: Play back or delete the recorded operations.
Recording Trace Memory (pan/tile/zoom operations)
• Select the trace number you want to record in TRACE NO.
• Move the cursor to RECORD and press the HOME button (or Joystick right click).
*Setting menu (enter to record) is display at the top left corner of the screen
• Move the camera position to the Start Position where you want the Trace to start from.
*Recording status is display at the top of the screen
• Call preset 1 to start the trace recording
• Perform the pan/tilt/zoom operations you want to record, during recording, elapsed commands number
at the top of the screen increases in increments of 1 when the camera received one command.
NOTE: If using the remote commander, pan/tilt/zoom operations can’t be performed simultaneously.
If using the joystick controller, pan/tilt/zoom operations can’t be performed simultaneously
• Call preset 1 to finish and stop the trace recording
NOTE: The recording automatically stops after the maximum recording time has elapsed.
Playing Trace Memory (pan/tilt/zoom operations)
• Select the recorded trace number you want to play in TRACE NO.
• Move the cursor to MEMORY, select PLAY and press HOME button (or Joystick Enter button) to begin
playback.
NOTE: Playback stops if a pan/tilt/zoom operation is performed during playback by using the remote
commander or a joystick controller.
Deleting recorded Trace Memory (pan/tilt/zoom operations)
• Select the trace number you want to delete in TRACE NO.
• Move the cursor to MEMORY, select DELETE and press HOME button, it will display “DELETE
TRACE YES”, press HOME button again, this trace will be deleted.
GENLOCK
This is the external sync signal input, it supports BBS
(Black Burst Sync) and tri-level synchronization.
External synchronization (genlock) can be applied to
achieve phase alignment when multiple cameras are to
be used or when the unit is to be used in combination with
other devices.
Supply to the camera genlock connector the sync signals
that correspond to the video signal format which has been
set.
• External synchronization is performed using the SDI video
signal. Synchronization is not possible using the HDMI video
signal or the IP video signal.
EXT.SYNC
Set to ON, external synchronization (genlock) will be enabled, set to
OFF to disable external synchronization
H PHASE
This is used to adjust the horizontal phase during genlock
H PHASE FINE
This is used to single digit fine tuning of horizontal phase during
genlock
• NOTE: Horizontal phase setting range is 0 to 1920
V PHASE
This is used to adjust the vertical phase during genlock
V PHASE FINE
This is used to single digit fine tuning of vertical phase during genlock
• NOTE: Vertical phase setting range is 0 to 1080
EXPOSURE
WHITE BALANCE
DETALL
>PICTURE
GAMMA
NETWORK
PAN TILT ZOOM
>GENLOCK
STSTEM
STATUS
OSD
EXT.SYNC ON
H PHASE 127
H PHASE FINE 0
V PHASE 000
V PHASE FINE 7
SYSTEM MENU
