3. External device connection diagram
Model 1: DC Power
Model 2: PoE
Ethernet switch
WAN
DC input
NC COM NO
Alarm light
Relay in
Call-in Switch
or
Optional power adapter*
External
Audio Device
Alarm light
NC COM NO
Relay in
Call-in Switch
or
PoE+ switch
WAN
2. Wiring harness
Serial
number
Description
Interface
➀
➀
Ethernet interface: standard RJ45 interface, 10/100M adaptive, support
PoE+ powered, it is recommended to use CAT5 or better network cable.
Power interface: DC 24V/2A input.
The short circuit input interface: input devices for connecting
call-in switches.
The short circuit output interface: Can be enabled via Nyquist web
interface station parameter "External Relay Trigger" to close the contact
whenever audio is being received by the Nyquist server and played by
the NQ-IPHRN01 speaker.
➁
➁
➂
➂
➃
➃
+
-
+ S1
-
➀
NO
➁
COM
➂
NC
GND
①
②
③
Relay out
Relay out
External
Audio Device
*Optional power adapter or PoE+ power injector
