MX44AVW USER MANUAL
Contact: support@blustream.com.au | support@blustream-us.com | support@blustream.co.uk
15
Web-GUI - Multiview Mode (continued)
Output:
– The output windows displays a render of the location and size of each window in the Multiview configuration
– The windows can be moved around by pressing and dragging the window to the desired position. The scale can be
modified by using the sizing handles at the corner of each window
– When a fixed aspect ratio is selected for the window, the window will be forced re-sized to maintain the selected aspect
ratio
Window:
Select the multiview window to modify. Any changes in the following sections will be applied to the selected window. The window
can also be disabled using the ‘Active’ toggle
Layout Priority (setting applied to selected Multiview window):
– Sets the layer the window is on, aecting which windows render above or below the specified window
Aspect (setting applied to selected Multiview window):
Amends the aspect ratio of the selected window.
– Custom allows the aspect ratio to be manipulated manually, stretching or compressing the window to the ratio set
– 16:10 / 16:9 / 4:3 fixes the aspect to one of the 3 most common aspect ratios used across most media devices
Position & Size (setting applied to selected Multiview window):
– To set the position of the selected window, enter the desired location in the X & Y fields. The position coordinates refer to
the top le corner of each window. (0,0) begins at the top le corner of the output render
– To set the size of the selected window, enter the width and height in pixels into the respective fields. When a fixed aspect
ratio is selected for the window, the window will be forced re-sized to maintain the selected aspect ratio
– To flip the selected window horizontally and/or vertically, press the corresponding check box.
Border (setting applied to the selected Multiview window):
Enables a border around the window that is visible on the HDMI output
– It’s colour and width can be set using the respective fiel
– Press Apply to save the changes
Layouts:
– The MX44AVW contains 5 pre-loaded presets that can be switched to by pressing the corresponding preset button
– An additional 8 custom presets can be saved to easily recall settings and switch between multiple configurations.
Once configured, press the Save to Preset button to open a sub menu, and then select the desired preset number. The
configuration will be saved to the selected preset number
– The preset icon will change depending on the matrix configuration, allowing for easy identification of presets
Audio:
– All four HDMI outputs can be set to play audio from any of the HDMI inputs. It can also be set to play external audio through
the phoenix connector port
– Select the desired audio input corresponding to the desired output to route audio through the matrix
