HEX18GARC-KIT QUICK REFERENCE GUIDE

Contact: support@blustream.com.au | support@blustream-us.com | support@blustream.co.uk

The HEX18GARC-KIT allows for a variety of ways to transfer Audio Return from the Receiver back to the Transmitter unit.

By definition, ARC (Audio Return Channel) and Optical Audio Return, will support up to a maximum of 5.1ch HD audio

pass-through. For ARC via HDMI, CEC will need to be enabled on both the display and the AVR/processor for the required

communication to instigate the ARC channel to be opened. The HEX18GARC-KIT is transparent to this communication.

eARC (Enhanced Audio Return Channel), allows for high resolution audio codecs (including Dolby Atmos and DTS:X) to

travel back from an eARC display to an eARC AVR/processor. Both pieces of equipment connected to either side of the

HEX18GARC-KIT must be eARC capable for this function to work, and have CEC enabled.

The HEX18GARC-KIT will also allow for Optical Audio Return to be sent across the HDBaseT

™ link. Please ensure the

correct DIP switch settings on both Transmitter and Receiver are selected for the required audio transmission method.

The HEX18GARC-TX features an anlogue 2ch L/R audio breakout for a 2ch audio return feed from the display connected

at the Receiver. Please note: this output port is not audio breakout of the HDMI audio being fed to the HDMI input of the

Transmitter, nor does the Transmitter down mix multi-channel audio codecs.

ARC, eARC, and Optical Audio Return

The HEX18GARC-KIT features a 1Gbps LAN pass-through for bi-directional communication and distribution of data.

The connections are transparent to the HDBaseT™ link, and the HEX18GARC-KIT does not act as router or DHCP server

for the equipment connected either side.

Ethernet / LAN Pass-through

The HDBaseT™ chipset used in this HEX18GARC-KIT allows for USB2.0 pass-through, to speeds of up to 350Mbps

(combined) for connectivity of a USB Host to USB peripheral devices on the other side of the HDBaseT™ link. The USB

link is designed for connection of KVM devices, and as such, may not support all USB2.0 equipment dependng on the

type of USB data transfer. Please ensure that the relevant DIP switches have been set to select whether the Transmitter

or Receiver is acting as the ‘Host’ and ‘Device’ connection.

Where the TX or RX unit is selected as the ‘Host’, the other end of the link must be set to ‘Device’ using the DIP switches

on the individual units. It is not required to download any drivers or soware for the HDBaseT

™ equipment to allow for

USB data transfer.

Please note: it is not possible to have both Host AND peripheral Devices connected at both ends of the HDBaseT

™ link

running simultaneously.

USB Pass-through

The HDBaseT™ VS3000 chipset used in this HEX18GARC-KIT features ‘Port Duality’ for a 1080p return stream (RX to TX)

to run simultaneously with the 4K stream from TX to RX. At the point of the release of this product to market, the Port

Duality function is still undergoing development by HDBaseT™, and will be released at a later date. Blustream expects

to release a firmware update to the HEX18GARC-KIT in the future to implement this feature into the product.

HDMI Input on HEX18GARC Receiver

The HEX18GARC-KIT is designed by default to provide power to USB devices whether or not a USB Host is connected.

Depending on the USB hardware, this may or may not be the desired function. It is possible to change this function so

that USB power is not provided when there is no USB Host connection. This function can be adjusted via RS-232 using

the API command USBDP FH or ON. This feature has been implemented from Revision ‘C’ units onward. Please see the

User Manual available on the Blustream website for further details.

USB Power
