10
Panels – A Closer Look (cont’d)
Headphone Level Control and Output
Polar’s headphone output is designed
to drive both low and high impedance
headphones, providing clear and accurate
monitoring.
The Headphone Output Jack is a ¼”
stereo jack.
The dedicated Headphone Level Control allows you to adjust the headphone
level independently from your monitors.
If your headphones only have a 3.5mm connector, you can use a stereo 3.5mm
to stereo 6.35mm (1/4”) adapter to connect to Polar’s headphone output.
Using headphones with a TS or TRRS connector (such as headphones with a
microphone or volume control built into the cable) will most likely not work. We
always recommend using headphones with a stereo connector and/or stereo
adapter.
Balanced Outputs
Outputs 1/L and 2/R are line-level outputs
designed to connect your Polar 2 to active
monitors or an amplier. These outputs use
balanced 1/4” TRS jacks and can accommodate
both unbalanced TS and balanced TRS jack
cables.
The Monitor Level Control on the top panel of your Polar 2 adjusts the output
level for Outputs 1/L and 2/R.
DC 5V Power Input
Most computers will have no issues supplying power to your Polar 2 over USB,
however, if you are using additional peripherals or high-power devices alongside
your Polar 2, the computer’s USB port may not supply enough power.
You’ll usually know when this happens if the Polar 2 keeps disconnecting during
intense usage, for example, playing headphones at a loud
level and powering two condenser microphones with
phantom power.
For these cases, the DC 5V Power Input allows you to
power your Polar Audio Interface using DC 5V power. Use
the included USB to 5V cable to connect your adapter to
any standard DC 5V power adapter.
USB-C
The USB-C connection on the Polar Audio Interface is used
to connect the interface to your computer. This connection
facilitates power supply, data transfer, and communication to the
Polar Control software.
Use the included USB-A to USB-C cable to connect directly to
an open USB-C port on your computer.
IMPORTANT: Avoid connecting your Polar 2 to your computer using a USB hub, as this will
cause issues and is not supported.
NOTE: When using iOS devices, you must power your Polar 2 with DC 5V. For more details,
see the iOS section on page 22.
OFF
ON
+48V
HEADPHONES
1/L
2/R
OUTPUTS
USB-C
DC 5V 1A
1/L
2/R
OUTPUTS
USB-C
DC 5V 1A
1/L
2/R
OUTPUTS
USB-C
DC 5V 1A
