12 | Chapter 2: Hardware installaon
2.5 Expansion Slots
PCI1/PCI2/PCI3: Peripheral Component Interconnect Slots
The PCI slots support cards used in PCs include: LAN cards, sound cards, modems, TV •
tuner cards and other cards that comply with PCI standard.
PEX16_1: PCI-Express Gen3 x16 Slot (x16 speed)
• PCI-Express 3.0 compliant.
• Maximum theorecal realized bandwidth of 16GB/s simultaneously per direcon, for an
aggregate of 32GB/s totally.
PEX16_2: PCI-Express Gen3 x16 Slot (x4 speed)
• PCI-Express 3.0 compliant.
• Data transfer bandwidth up to 4GB/s per direcon; 8GB/s in total
PEX1_1: PCI-Express Gen3 p12-x1 Slot
PCI-Express 3.0 compliant.•
Data transfer bandwidth up to 1GB/s per direcon; 2GB/s in total•
Install an Expansion Card
You can install your expansion card by following steps:
• Read the related expansion card’s instrucon document before install the expansion
card into the computer.
• Remove your computer’s chassis cover, screws and slot bracket from the computer.
• Place a card in the expansion slot and press down on the card unl it is completely
seated in the slot.
• Secure the card’s metal bracket to the chassis back panel with a screw.
• Replace your computer’s chassis cover.
• Power on the computer, if necessary, change BIOS sengs for the expansion card.
• Install related driver for the expansion card.
