USING THE HOB

It is advisable to clean the hob daily after every use, once it has cooled down, using specic products for steel, or a normal degreaser for coloured cookers.

Be careful to remove all cooking residues. We strictly advise you against using abrasive or chlorine-based products.

CLEANING THE PAN SUPPORTS

The pan supports must be cleaned on a regular basis with warm water and non-abrasive detergent, being careful to remove all incrustations.

CLEANING THE BURNER BLACK CAPS AND FLAME SPREADERS

The burner caps and ame spreaders can be taken off to make it easier to clean the hob. Wash them with hot water and non-abrasive detergent, making

sure they are thoroughly dry before being re-installed.

CLEANING THE BURNER BLACK CAPS AND FLAME SPREADERS

The burner caps and ame spreaders can be taken off to make it easier to clean the hob. Wash them with hot water and non-abrasive detergent, making

sure they are thoroughly dry before being re-installed.

CLEANING THE SPARK PLUGS AND THERMOCOUPLES

To avoid malfunctions, check and keep the hob spark plugs and thermocouples clean. Remove any cooking residues by wiping them gently with a damp

cloth.

CLEANING THE OVEN

For a good preservation of the oven it must be cleaned regularly after it has cooled down.

• Remove all removable parts.

• Clean the oven grids with hot water and non-abrasive detergents, rinse and dry.

• to make cleaning easier, it is possible to take the door and/or the glass off (refer to the maintenance paragraph).

• At the end of these operations,to dry the damp parts thoroughly. It is advisable to turn the oven on for a maximum of 15/20 minutes after the use of

specic cleaning products, in order to eliminate any residues from the inside of the oven.

• Do not use abrasive detergents or metal scrapers to clean the oven door glass as this may scratch the surface of the glass, causing its breakage.

MAINTENANCE

WARNING

Prior to every maintenance operation it is necessary to unplug the appliance from the power socket and wait for it to cool down completely.

CHANGING THE BULB INSIDE THE OVEN (g. 7 - page 10)

Unscrew the protective protruding cap inside the oven (A). Unscrew and change the bulb (B) with a new one with the same power and resistance to high

temperatures (300°C). Put the cap back in place by screwing it in clockwise.

OVEN DOOR REMOVAL

DOOR WITH TRADITIONAL HINGE

(g. 8 - page 10)

• Lift levers B and hold the door by its two sides with both hands, near hinges A.

• Lift the door upwards at an angle of approx. 45° and carefully pull it out. To re-assemble it, t the hinges into the relative grooves, then let the door slide

downwards, and release levers B.

DOOR WITH COMPACT HINGE (g. 9 - page 10)

• Lift levers “2” up to the ledge with hinges “1” and hold the door by its two sides with both hands, near the hinges.

• Lift the door upwards at an angle of approx. 45° and carefully pull it out.

• To re-assemble it, t hinge “2” into the relative grooves, then let the door slide downwards, making sure it stays

blocked in the grooves “3”, then release levers “1”.

CLEANING

It is necessary to periodically clean the oven thoroughly to avoid the formation of grease, which over time can produce smoke, unpleasant odour and

malfunctions. Below is a list of our tips concerning the various parts of your cooker.

WARNING

Do not use jets of steam to clean the appliance.

Steam could reach the electrical parts, damaging them and causing short circuits.

Do not use cleaning products that contain chlorine, ammonia or bleach on parts made of steel or supercially treated with metal nishes

(for example anodizing, nickel-plating, chrome-plating).

REMOVING THE GLASS FROM THE OVEN DOOR (only in applicable models)

This operation can only be carried out when the appliance is cold.

To take the glass out from the oven door, you must do the following:

• Open the door slightly.

• Press the black keys located on the side supports of the door at the same time, and slide them upwards.

• Remove the top prole of the door.

• Take the glass out by pulling it towards you.

To re-install the glass, follow these steps in reverse order being careful to align the glass with the side supports and making sure that the letters VIT are in

the bottom right corner marked by the arrow. Lastly, put the top prole back in place on the door.
