19R5916765 /01 MUIP-2213
Mission critical applications
We strongly recommend to immediately have a replacement display available in mission critical applications.
Use of electrical surgical knives
Provide as much distance as possible between the electrosurgical generator and other electronic equipment
(such as LCD User Interfaces). An activated electrosurgical generator may cause interference with this
equipment and can disrupt the functionality of the display.
Power connection (the configuration without power supply)
• Power requirements: The equipment must be powered using medical approved AC/DC power supply.
• The medical approved AC/DC power supply must be powered by the AC mains voltage.
• The equipment should be installed near an easily accessible wall socket.
• To disconnect the main power, unplug the AC adapter.
• The equipment is intended for continuous operation.
• The compliance of the equipment with the Medical Safety and EMC requirements has been evaluated with
the provided medical grade power supply. If a different power supply is used, further investigation for
Safety and EMC requirements have to be performed at system level.
• Do not use the supplied AC adapter for powering other devices.
• Do not move the equipment while the power cord and connection cables are connected. Otherwise,
damage to the equipment, power cord and connection cables, fire or an electric shock may result.
Power connection – Equipment with external 19V VDC power supply
• Power requirements: The equipment must only be powered using the delivered medical approved 12-24
VDC ( ) SELV power supply.
• The medical approved DC ( ) power supply must be powered by the AC mains voltage.
• The power supply is specified as a part of the equipment.
• To avoid the risk of electric shock, this equipment must only be connected to a supply mains with protective
earth.
• The equipment should be installed near an easily accessible outlet.
• The equipment is intended for continuous operation.
• The compliance of this LCD User Interface with Medical Safety and EMC requirements has been
evaluated using the external (optional) medical power supply model 'TR60M19'. If a different power supply
will be used, further investigation for safety and EMC requirements have to be performed at system level.
Transient over-voltage
To fully disengage the power from the device, please disconnect the power cord from the AC inlet.
Connections
Any external connection with other peripherals must follow the requirements of clause 16 of IEC60601-1 3rd.
Ed. for the medical electrical systems.
To maintain compliance with EMC Regulation, use only shielded interface cables for the connection to
peripheral devices.
Power cords:
• Please use the power cord provided with this equipment. If a power cord is not supplied with this
equipment, please contact your supplier. For all other cases, please use a power cord that matches the AC
voltage of the power outlet and has been approved by and complies with the safety standard of your
particular country.
• Do not overload wall sockets and extension cords as this may result in fire or electric shock.
• Mains lead protection: Power cords should be routed so that they are not likely to be walked upon or
pinched by items placed upon or against them, paying particular attention to cords at plugs and
receptacles.
• The power supply cord should be replaced by the designated operator only, at all times.
