4.1 Status Indications
The top LED will help you to identify the current radio status.
LED Indication
What it Indicates
Constant Green
Receiving Signal
Constant Red
Transmitting signal
Flashes Green
Monitor mode/Scanning Receiving
4.2 LCD icon summary
Icon
Description
Battery level indicator
Make sure you can hear the DTMF side tone from the radio speaker, set to DT-ST, ANI-ST, DT+ANI.
Dual watch enabled
VOX enabled
Bluetooth frequency writing function activated
GNSS function enabled
Keypad lock enabled
Indication of the current channel's region. Working in storage mode
In the current working VFO mode. Allow manual frequency input
A displays (upper section) and emission level indication
B displays (lower section) and emission level indication
Squelch Open/ Close Indicator
Transmit power level indicator, According to Power High
The current transmission power is medium power (used in normal environments).
Transmit power level indicator, According to Power Low
DCS enabled
CTCSS enabled
Enables access of repeaters in VFO/Frequency Mode. TX will be shifted higher in frequency than RX
DŽ
Enables access of repeaters in VFO/Frequency Mode. TX will be shifted lower in frequency than RX
Reverse function enabled
