Note: there are 50 groups of CTCSS tones.

(7) Receiving DCS (Rx DCS) – + 7

DCS codes are similar to access codes and can be added to channels, so as to create a sort of personal channel. They enable the radio to communicate with

the users that are tuned on the same channel and have set the same DCS code. You can choose amongst:

• Off: Off

• D023N-D754N (Normal DCS), D023I-D754I (Inverse DCS)

Note: In radio there are 208 groups of normal and inverse DCS codes.

(8) Transmitting CTCSS (Tx CTCSS) – +8

In this Menu you can set a CTCSS tone in tx mode.

You can choose: Off or CTCSS (67.0 to 254.1 Hz)

Note: there are 50 groups of CTCSS tones.

(9) Transmitting DCS (Tx DCS) – +9

In this Menu you activate DCS codes in tx mode. You can choose between normal R-DCS (D023N-D754N) and inverted R-DCS (D023I-D754I)

Note: the groups of DCS codes are 208.

(10) Call Encryption (Encryption) – +10

If the channel is configured with CTCSS/DCS and encryption is turned on, the communication will remain private.

Allows setting CTCSS/DCS code in RX/TX CTCSS/DCS menu.

The encryption icon will be displayed on the screen when the encryption function is turned on.

(11) Signal code (Signaling) – +11

Selects 1 of 20 DTMF codes. The DTMF codes are programmed with software and are up to 3 digits each.

(12) Working Mode (CH-MDF) – +12

This function is used to set the display mode of the current channel. The radio offers three working modes:

• NAME: Channel name

• FREQ: Frequency Mode

• CH: Channel Mode

NOTE: The channel name allows editing via the CPS programming software and the channel Name in the Program Channel.

(13) Monitor (SP-MUTE) – +13

With this function, the monitor opens if one of these options is detected:

• QT: When radios is set in this mode, the monitor feature is activated only when the radio receives the correct CTCSS tones.
