FLOOR MODEL GAS DECK OVEN OPERATION MANUAL
7
INSTALLATION INSTRUCTIONS
Pilot Burner Lighting Procedure:
(a) Partially depress and turn the gas cock dial to
‘OFF’ position.
(b) Wait for five minutes to allow gas, which may
have accumulated in the burner compartment, to
escape.
(c) Turn gas cock dial to ‘PILOT’ position.
(d) Depress gas cock dial and light Pilot Burner. Hold
in pressed position for about 1/2 minute (30
seconds), and release the gas cock dial. The Pilot
Burner should now remain lit.
If Pilot Burner fails to ignite or does not remain lit,
repeat the steps (a) through (d).
Pilot Burner Flame Adjustment:
It is important to have the correct Pilot Burner Flame
size as shown in Fig.10. If necessary, adjust the Pilot
Burner Flame by turning Pilot Adjust Screw (See
fig.11) clockwise to reduce or counterclockwise to
increase
Figure 10
Figure 11
Burner Operation:
(A) Main Burner:
After the pilot burner is ignited, when heat is
desired, turn gas cock dial to ‘ON’ position
and set the thermostat dial to the desired
temperature. The oven burner flame should
always have a blue appearance. That indicates a
good mixture of gas and air. When using LP gas,
the flame will have a blue-yellow appearance.
Should the Burner fail to light, check to see if
there is a problem with the gas supply. lf there
are other appliances on the same line, shut them
off temporarily and see if the burner comes
back on, or it fluctuates as other gas appliances
are turned on and off. That would indicate
overloading of the gas supply lines or a faulty
gas pressure regulator. Contact an authorized
Service Agency or your local Gas Supply
Company.
(B) Aeration And By-Pass Flame Adjustment:
Flame and air mixer adjustments and the By-
Pass Flame adjustment for the Main Burner
are done at the factory. These adjustments
are sealed before the oven leaves the factory.
Contact an authorized Service Agency if you
need help.
Thermostat Calibration:
No attempt should be made to calibrate the
thermostat because it is accurately calibrated and
sealed by the manufacturer. Contact an authorized
Service Agency if you need help.
Flame Diverters:
Flame diverters distribute the heat evenly below
the baking deck. They must be in good condition
and properly placed above the burners in the burner
chamber in order to be effective. Damaged or
improperly installed flame diverters adversely affect
the oven performance. Make sure that the ‘V’ shaped
diverters are pushed all the way to the back of the
oven as far as they will go. Check them periodically
and replace them as necessary.
