2-Thread Subsidiary Looper

Either needle thread may be engaged for 2-thread overlock sewing.

To engage the subsidiary looper

1. Open the front cover and the cutting blade cover, cut the upper

looper thread just above the threading port (g. A). Raise the

presser foot and remove the thread from the upper looper.

2. Rotate the handwheel to bring the needle clamp to its highest

position.

3.Guide the subsidiary looper to the right and swing it counterclock

-

wise to the left (g. B).

4. Make sure the hooked tip of the subsidiary looper enters into the

upper looper eye (g. C).

5. Close the cutting blade cover and the front cover.

To disengage the subsidiary looper

1. Open the front cover and the cutting blade cover.

2. Rotate the handwheel to bring the needle clamp to its highest po

-

sition.

3. Guide the subsidiary looper to the left and swing it clockwise to the

right (g. D).

4. Make sure the subsidiary looper is resting at the right side of the

upper looper (g. E).

5. Close the cutting blade cover and the front cover.

1

2

1

2

1

2

1

2

1

2

AA

BB

CC

DD

EE

Cutting Blade Cover Seam Guide

Use the marks on your serger's cutting blade cover to align the fabric

edge for the desired seam width. Set the stitch dial at the "M" setting

for accurate seam allowances.

1. The chain stitch (C-3) combined with the 3-thread overlock is the

most common 5-thread combination. The mark closest to the nee

-

dles indicates 5/8 inch (16mm) from the cutting edge to the C-3

chain needle.

2. When using the left overlock needle (O-1) for either a 3 or 4-thread

overlock seam, the second mark from the needles indicates

5/8 inch (16mm) from the cutting edge to the O-1 overlock needle.

3. Use the right overlock needle (O-2) for 3-thread overlock seam

and the third mark from the needles indicates 5/8 inch (16mm)

from the cutting edge to the O-2 overlock needle.

4. Other marks on the front cover are for any custom seam allow

-

ance.

NOTE: Be sure to set the stitch dial at the "M" setting for accurate

seam allowances when using the cutting blade cover seam guide.

5/8 inch

5/8 inch

O

V

E

R

V

I

E

W

14
