Setting Up Your Splendor

1. Remove machine from box

After removing the packing materials from

the box, gently lift your Baby Lock serger by

grasping the handle provided on the top of the

machine.

Place the machine on a serger/sewing table

or any level surface that provides ample work

area to the left. Place the foot controller in a

pedal stay, if desired, and place it under the

sewing table.

2. Plug in the machine

Plug the power cord into the machine first,

then into a wall outlet. The power switch is lo

-

cated toward the back on the right side of the

machine.

Always make sure the power is off when the

machine is not in use (fig. A).

Lay the foot control cord and power cord

along the inside of the channel located on the

bottom right side of the machine (fig. B).

Note: Available foot control for 110-120V

area: YC-482. for 220-240V area: Model YC-

483N-1 or YC-483N or YC168S.

3. Polarized plug (U.S.A and Canada only)

This appliance/machine has a polarized plug

(one blade wider than the other). To reduce

the risk of electric shock, this plug is intended

to fit in a polarized outlet only one way. If the

plug does not fit fully in the outlet, reverse the

plug. If it still does not fit, contact a qualified

electrician to install the proper outlet. Do not

modify the plug in any way.

4. Foot controller

The sewing speed of the machine is deter

-

mined by the amount of pressure applied to

the foot controller.

When not in use, do not place anything on the

foot controller, the machine could start inad

-

vertently and the foot controller or motor could

burn out.

5. Spool pin extension table

To insert the spool pin extension place the

pegs into the slots on the back of the main

thread spool stand.

Push the extension thread stand onto the main

thread spool stand until it snaps into place

(g. C).

Removing the spool pin extension table:

Hold the back of the extension table with

both hands. Raise it up and out to release

from the main thread spool stand (g. D).

AA

BB

CC

DD

S

E

T

T

I

N

G

U

P

15
