26 | www.BabyLock.com

Bobbin and Bobbin Tension

The Gallant XL Stationary quilting machine uses M-class bobbins that are much larger than home

sewing machine L-class bobbins. The larger bobbins hold more thread and enable you to quilt for a

longer time between bobbin changes.

To wind the bobbin

The Gallant XL Stationary quilting machine comes with a separate bobbin winder. For full

instructions about using the bobbin winder, see the instruction manual that is packaged with the

bobbin winder.

To insert the bobbin into the bobbin case

U CAUTION: To prevent personal injury, always turn o the power switch while inserting and/

or removing the bobbin case or anytime your hands are near the needle area, such as when

you change the needle or the hopping foot.

1. Place the bobbin in the bobbin case

so the thread is wound clockwise and

coming o top right.

2. Take the thread tail and direct it into

the slot in the bobbin case. Pull the

thread back and under the tension

spring as shown here (point to picture).

The thread will then backtrack through

the slot.

3. Pull the thread back and under the

tension spring as shown here. The

thread will then backtrack through the

slot.

4. When the bobbin is threaded properly

under the tension spring, the bobbin

will rotate counter-clockwise when the

thread is pulled o the bobbin.

 NOTE: The rule is for the thread to backtrack as it comes o the bobbin under the tension

spring. It should rotate the opposite way it is wound. It should not rotate the same direction

it is wound.
