Gallant XL Staonary User Manual | 27

To test bobbin tension

The bobbin tension is the foundation for stitch tension. Always set the bobbin tension rst.

 NOTE: Check the bobbin tension each time a new bobbin is inserted.

1. With the bobbin properly in the bobbin case, hold the bobbin case in the palm of your hand

with the open end facing up.

2. Wrap the thread once around the index nger of the opposite hand and attempt to lift the

bobbin up by the thread. The bobbin case should stand up on its side, and barely lift out of

your hand. If the bobbin will not stand up on its side, the bobbin tension is too loose. If it

lifts completely out of your hand and hangs by the thread, the bobbin tension is too tight.

To adjust the bobbin tension

• Make the adjustment using the screw in the center of the

tension spring (the larger of the 2 screws). Turn clockwise

(to the right) to tighten and counterclockwise (to the left) to

loosen the tension. Make tiny adjustments to the screw and

test again.

To insert the bobbin case into the machine

1. Move the needle to the up position by turning the hand wheel in direction of motion until

the needle is at its highest position. Turn the Gallant XL Stationary quilting machine OFF at

the back of the machine.

2. Place the bobbin in the bobbin case.

3. Leave 5 to 6 inches of thread hanging loose.

4. To t the bobbin case onto the hook spindle in the machine, orient the bobbin case as

shown in the photo with alignment tab into the notch to the right. Push the bobbin case

inward until it clicks into place.

 NOTE: Do not insert the bobbin case into the

machine by lifting the release lever on bobbin

case. Use the lever only for removing the bobbin

case.
