METRA. The World’s best kits.™ metraonline.com1-800-221-0932
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Installation Instructions for AXVI-2105
REV. 8/6/2020 INSTAXVI-2105
(continued on next page)
GM/Suzuki 2006-up
AXVI-2105
GM LAN 29 accessory and NAV output interface
WIRING THE AXVI-2105
• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
• Connect the Black wire to the radio’s ground wire.
• Connect the Red wire to the ignition wire of the aftermarket radio.
• Connect the Orange wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire, tape off the Orange wire.
• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.
• Connect the White wire to the left front positive speaker output of the aftermarket radio.
• Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio.
• Connect the Gray wire to the right front positive speaker output of the
aftermarket radio.
KIT FEATURES
• Provides accessory (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Used in non-amplified systems or when replacing amplified system
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired AXSWC harness included (AXSWC sold separately)
• High level speaker input
• USB updatable
Note: All chimes will be lost when using this harness
BUICK
Enclave 2008-up
Lucerne 2006-2011
CADILLAC
DTS 2006-2011
(only to be used when replacing
an amplified system)
Escalade 2007-2014
(only to be used when replacing
an amplified system)
SRX 2007-2009
(only to be used when replacing
an amplified system)
CHEVROLET
Avalanche 2007-up*
Captiva Sport 2012-up
Cheyenne 2012-up *
Equinox 2007-2009
Express 2008-up
Impala 2006-2013
Impala limited 2014
Monte Carlo 2006-2007
Silverado (new body) 2007-13*
Silverado 2500/3500 2014 *
Suburban 2007-2014*
Tahoe 2007-2014*
Traverse 2009-up
GMC
Acadia 2007-up
Savanna 2008-up
Sierra (new body) 2007-13*
Sierra 2500/3500 2014*
Yukon/XL 2007-2014*
HUMMER
H2 2008-2009
PONTIAC
Torrent 2007-2009
SATURN
Outlook 2007-2010
Vue 2008-2010
SUZUKI
XL-7 2007-2009
APPLICATIONS
*Non-navigation models only
