AXVI-2105
METRA. The World’s best kits.
™
metraonline.com1-800-221-0932
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
REV. 8/6/2020 INSTAXVI-2105
• Connect the Gray/Black wire to the right front negative speaker output of the
aftermarket radio.
• Connect the Green wire to the radio’s left rear positive speaker output.
• Connect the Green/Black wire to the radio’s left rear negative speaker output.
• Connect the Purple wire to the radio’s right rear positive speaker output.
• Connect the Purple/Black wire to the radio’s right rear negative speaker output.
The following wires are for the aftermarket radios that have navigation built in.
• Connect the Light Green wire to the parking brake wire of the aftermarket
navigation radio (if applicable).
• Connect the Blue/Pink wire to the VSS or speed sense wire of the aftermarket
navigation radio (if applicable).
• Connect the Green/Purple wire to the reverse wire of the aftermarket navigation
radio (if applicable).
• Cycle the key, by turning the ignition on for 30 seconds. Then off and on again to
test the radio.
AXSWC (if installing)
After the interface is initialized, plug in the AXSWC into the 12-pin harness of the
AXVI-2105 and refer to the AXSWC instructions.
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Metra recommends MECP
certified technicians
IMPORTANT WARNING
This product includes instructions for installation which must be carefully followed. The
instructions are worded in such a manner to assume that the installer is capable of
completing these type of electronic installations. If you are unclear as to what you are
instructed to do or believe that you do not understand the instructions so as to properly
and safely complete the installation you should consult a technician who does have this
knowledge and understanding.
Failure to follow these instructions carefully and to install the interface as described
could cause harm to the vehicle or to safety systems on the vehicle. Interference with
certain safety systems could cause harm to persons as well. If you have any questions
in this regard please call the Help line or Metra at 1-800-221-0932 for assistance.
