AXVI-1784
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 1/21/20
AXVI-1784
AXVI-1784 AXVI-1784
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 1/21/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 1/21/20 © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 1/21/20
AXVI-1784
Dodge/Mercedes/Freightliner accessory and NAV output
CAN harness 2007-2013
• Provides accessory (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired AXSWC harness included (AXSWC sold separately)
• High level speaker input
• USB updatable
APPLICATIONS
WIRING UP THE AXVI-1784
• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
• Connect the Black wire to the radio’s ground wire.
• Connect the Red wire to the ignition wire of the aftermarket radio
• Connect the Orange wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire, tape off the Orange wire.
• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.
• Connect the White wire to the left front positive speaker output of the
aftermarket radio.
• Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio.
AXVI-1784
DODGE
Sprinter 2007
Sprinter
(sound 5 radio) 2008-2009
MERCEDES
Sprinter
(sound 5 radio) 2010-2013
FREIGHTLINER
Sprinter 2007
Sprinter (sound 5 radio) 2008-2013
Dodge/Mercedes/Freightliner accessory and NAV output
CAN harness 2007-2013
• Provides accessory (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired AXSWC harness included (AXSWC sold separately)
• High level speaker input
• USB updatable
APPLICATIONS
WIRING UP THE AXVI-1784
• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
• Connect the Black wire to the radio’s ground wire.
• Connect the Red wire to the ignition wire of the aftermarket radio
• Connect the Orange wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire, tape off the Orange wire.
• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.
• Connect the White wire to the left front positive speaker output of the
aftermarket radio.
• Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio.
DODGE
Sprinter 2007
Sprinter
(sound 5 radio) 2008-2009
MERCEDES
Sprinter
(sound 5 radio) 2010-2013
FREIGHTLINER
Sprinter 2007
Sprinter (sound 5 radio) 2008-2013
AXVI-1784
Dodge/Mercedes/Freightliner accessory and NAV output
CAN harness 2007-2013
• Provides accessory (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired AXSWC harness included (AXSWC sold separately)
• High level speaker input
• USB updatable
APPLICATIONS
WIRING UP THE AXVI-1784
• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
• Connect the Black wire to the radio’s ground wire.
• Connect the Red wire to the ignition wire of the aftermarket radio
• Connect the Orange wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire, tape off the Orange wire.
• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.
• Connect the White wire to the left front positive speaker output of the
aftermarket radio.
• Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio.
AXVI-1784
DODGE
Sprinter 2007
Sprinter
(sound 5 radio) 2008-2009
MERCEDES
Sprinter
(sound 5 radio) 2010-2013
FREIGHTLINER
Sprinter 2007
Sprinter (sound 5 radio) 2008-2013
Dodge/Mercedes/Freightliner accessory and NAV output
CAN harness 2007-2013
• Provides accessory (12 volt 10 amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse, and V.S.S.)
• Prewired AXSWC harness included (AXSWC sold separately)
• High level speaker input
• USB updatable
APPLICATIONS
WIRING UP THE AXVI-1784
• Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
• Connect the Black wire to the radio’s ground wire.
• Connect the Red wire to the ignition wire of the aftermarket radio
• Connect the Orange wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire, tape off the Orange wire.
• Connect the Blue wire to the antenna turn on wire of the aftermarket radio.
• Connect the White wire to the left front positive speaker output of the
aftermarket radio.
• Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio.
DODGE
Sprinter 2007
Sprinter
(sound 5 radio) 2008-2009
MERCEDES
Sprinter
(sound 5 radio) 2010-2013
FREIGHTLINER
Sprinter 2007
Sprinter (sound 5 radio) 2008-2013
