• Connect the Gray wire to the right front positive speaker output of the
aftermarket radio.
• Connect the Gray/Black wire to the right front negative speaker output of the
aftermarket radio.
• Connect the Green wire to the radio’s left rear positive speaker output.
• Connect the Green/Black wire to the radio’s left rear negative speaker output.
• Connect the Purple wire to the radio’s right rear positive speaker output.
• Connect the Purple/Black wire to the radio’s right rear negative speaker output.
The following wires are for the aftermarket radios that have navigation built in.
• Connect the Light Green wire to the parking brake wire of the aftermarket navigation
radio (if applicable).
• Connect the Blue/Pink wire to the VSS or speed sense wire of the aftermarket
navigation radio (if applicable).
• Connect the Green/Purple wire to the reverse wire of the aftermarket navigation radio
(if applicable).
• Cycle the key by turning the ignition on for 30 seconds, then “off” and “on” again to
test the radio.
AXSWC (if installing)
After the interface has been initialized, plug in the AXSWC into the 12 pin harness
of the AXVI-1784 and refer to the AXSWC instructions.
