From the 14-pin harness to the aftermarket radio:
• Tape off and disregard the Red wire, it will not be used in this application.
• Connect the Blue/White wire to the amp turn on wire (this wire must be
connected to hear sound from the factory amplifier).
• Tape off and disregard the Brown wire, it will not be used in this application.
• Connect the White RCA to the left front output.
• Connect the Gray RCA to the right front output.
• Connect the Green RCA to the left rear output.
• Connect the Purple RCA to the right rear output.
Note: If the radio does not have RCA outputs, or only one pair, use a line level
convertor (sold separately). Use Axxess part number AXLOC4-80A (4 channel) or
AXLOC-80A (2 channel) for best results.
The following wires are for aftermarket multimedia/navigation radios that provide
these wires (if not required, tape them off and disregard them):
• Connect the Light Green wire to the parking brake wire.
• Connect the Blue/Pink wire to the speed sense/VSS wire.
• Connect the Green/Purple wire to the reverse wire.
Note: Reverse wire is not available on manual transmission vehicles.
Note: To retain these wires, please follow the steps under: From the 2-pin
harness to the vehicle.
• Plug the 14-pin harness into the AXTO-MI1.
From the AXTO-MI1 harness:
(a) to the vehicle:
• Connect the Black wire with a fork connector to chassis ground.
(b) to the aftermarket radio:
• Connect the Black wire to the ground wire.
• Connect the Yellow wire to the battery wire.
• Connect the Red wire to the accessory wire.
• Connect the Blue wire to the power antenna turn-on wire.
• Connect the Orange wire to the Illumination wire (if the aftermarket radio has
no Illumination wire, tape off the Orange wire).
• Connect the White wire to the left front positive speaker output.
• Connect the White/Black wire to the left front negative speaker output.
• Connect the Gray wire to the right front positive speaker output.
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the Green wire to the left rear positive speaker output.
• Connect the Green/Black wire to the left rear negative speaker output.
• Connect the Purple wire to the right rear positive speaker output.
• Connect the Purple/Black wire to the right rear negative speaker output.
• Connect the 20-pin harness into the AXTO-MI1.
• Connect the 16-pin and 22-pin harness into the vehicle.
Connections to be made
