CONNECTIONS
From the AXRC-GMLN3 harness to the aftermarket radio, connect as indicated:
Black wire to the ground wire.
Yellow wire to the constant/memory wire.
Red wire to the accessory wire.
Blue wire to the antenna turn on wire.
Orange/White wire to the illumination wire.
Note: If the aftermarket radio has no illumination wire, tape off the Orange/White wire.
White wire to the left front (+) speaker wire.
White/Black wire to the left front (-) speaker wire.
Gray wire to the right front (+) speaker wire.
Gray/Black wire to the right front (-) speaker wire.
Green wire to the left rear (+) speaker wire.
Green/Black wire to the left rear (-) speaker wire.
Purple wire to the right rear (+) speaker wire.
Purple/Black wire to the right rear (-) speaker wire.
The following (3) wires are only for multimedia/navigation radios that require these wires.
Blue/Pink wire to the VSS/speed sense wire.
Green/Purple wire to the reverse wire.
Light Green wire to the parking brake wire.
