AX PIO-COM1
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION REV. 6/3/25 INSTAXPIO-COM1
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Panel removal tool • Phillips screwdriver
• Torx screwdrivers • Tape
• Wire cutter • Zip ties
• Crimping tool and connectors, or solder gun,
solder, and heat shrink
TABLE OF CONTENTS
Dash Disassembly .................................................. 2
Kit Preparation .......................................................2
Kit Assembly ..........................................................2
Axxess Interface Installation
Interface Installation ........................................3
Dash Assembly .................................................. 4
Radio Operation ............................................ 5-6
Odometer Type .................................................7
Radio Integration Package for Pioneer
®
Radios
Fits Jeep Compass 2017.5-2021
• Designed for non-amplified vehicles
•
Designed for Pioneer
®
DMH-W4600NEX/W4660NEX or DMH-WC5700NEX receivers
• Allows for the retention and adjustment of the factory personalization menu
through the Pioneer
®
radio
• Provides a visual view of HVAC and gauges on the Pioneer
®
screen (cannot be
adjusted via the screen)
(Features continued on next page
)
KIT COMPONENTS
• A) Radio trim panel • B) Radio brackets • C) Panel clips (7)
Not shown: LD-CH5-PIO, LD-CHRYHAZ2T,
Radio interface, PR04AVIC-PIO or PR04-PIORCA Harness,
External Speaker
A B
C
WIRING & ANTENNA CONNECTIONS
Wiring Harness: Included with Kit
Antenna Adapter: Included with Kit
GPS Antenna Adapter: Included with Kit
Visit AxxessInterfaces.com
for up-to-date vehicle specific applications.
Product Info
IMPORTANT: TPMS will only display on the instrument cluster, not on the Pioneer
®
.
Visit MetraOnline.com for more detailed information about the product and up-to-date
vehicle specific applications
INTERFACE FEATURES
