4
EXTERNAL SPEAKER
LD-AX-SPK
Pioneer Harness
LD-GMLAN10-PIO
LD-BACKCAM-MOST
CARSIDE CONNECTORS (CONNECT TO EXTENSION)
MICRO-HDMI
ADAPTER NEEDED
(N/A)
EXT SPKR
CAN 2
CAN3
“TBA” WIRES
AD-EU5
CAMERA (IOB)
AUX (N/A)
High-Level
PRO4-AVIC-PIO
USB/AUX
(USE INSTEAD)
AXXESS INTERFACE
CONNECT TO
CLIMATE PANEL
CONNECT
TO PLUG REMOVED
FROM CLIMATE
PANEL
PRO4-PIORCA
Low-Level
(IO5 or IO6)
LOCATED
AT HMI
AUX (INCL. W/RADIO)
GPS
4-PIN MIC HDMI
ANT
18P (M)
18P (F)
16P 22P
10P
10P
40-GPS-PIO
10
CONNECTIONS
Important: Verify the backup camera
installation, HVAC status l, Steering wheel
audio controls, and External Speaker
output prior to completing dash assembly.
Important: Install the provided
speaker in the dash prior to assembling
the radio components.
Note: Make sure this is mounted in a
location suitable for the driver to hear.
(Audio level for the speaker can be
changed via the radio, once installed.)
