5
REV. 5/10/25 INSTAXDSPX-BMWM25
(Figure B)
8. Scroll to the Configuration tab then select the vehicle type. Press the Lock Down
button to save the configuration. (Figure B)
9. Connect the Blue/White amp turn-on wire.
10.
Click the
Identify
button to confirm the interface is connected properly. A chime will
be heard from the front left speaker. Test all functions of the installation for proper
operation
.
Note: The outputs may need to be configured within the Outputs tab.
11.
Adjust the DSP settings in the app as desired. Refer to the instructions under the
Setup Instructions tab, or online at Axxessinterfaces.com for an explanation of each
tab in the app.
If the Red light in the interface is blinking, it is not communicating with the vehicle.
1. Cycle the key off.
2. Unplug the connectors from the vehicle to the interface.
3. Inspect that all connections are made properly.
4. If everything is correct, connect the harnesses back into the interface, and cycle the
ignition on. The Red light should now be solid.
I N STALL ATI O N (CONT.)
