3
REV. 5/10/25 INSTAXDSPX-BMWM25
Installing the Fiber Optic Cable:
Removal of the original fiber optic
connection is required to adapt to the
Media Oriented System Transport
(MOST) interface. The black connector
housing uses a different keyway than
the MOST interface.
• From the original Fiber Optic
Connector: Using a pick tool, carefully
pull this tab towards the outside edge
for the connector housing. Gently
remove the fiber optic insert from the
connector. (Figure A)
(Figure A) (Figure B)
INSTALLING THE FIBER OPTIC CABLE
• From the MOST Interface: Using the same
steps from above, remove the gray insert
from the black fiber optic housing. Replace
the gray connector with the fiber optic cables
into the MOST interface’s black connector
housing. (Figure B)
• Plug the MOST connector into the fiber
decoder box.
