6
CONNECTIONS TO BE MADE AT THE FACTORY RADIO’S LOCATION (CONT)
1
14
13
2 12
24
32
22232425262728293031
21
10
9 8 7
3 2 14
6 5
20 19 18 17 16 15 14 13 12
11
T-Harness
Installation
Location
Run speaker wires to aftermarket amplifier(s)
Interface kit includes two T-harnesses to tap into the
speakers powered from the vehicle radio chassis
22 Pin
32 Pin
Located Behind Dash
OR
Factory Radio Chassis
Wire Insertion View
Viewed from where the wires go into the connector
LD-FDSPK1
LD-FDSPK2
Factory Radio Harness
To OE Speakers
NOTE: For Factory Amplifier Locations,
please see Speaker Assignment QR Code
located on the back page of these instructions.
