7
REV. 3/7/25 INSTAXDIS-MB82
INSTALLING THE FIBER OPTIC CABLE
Installing the Fiber Optic Cable:
Removal of the original fiber optic connection
is required to adapt to the Media Oriented
System Transport (MOST) interface.
•
Seat the AXDIS-MB82 amplifier interface
in the black connector housing provided
with this kit and snap the housing in place.
(Figure A)
• From the original Fiber Optic Connector:
Using a pick tool, carefully pull this
tab towards the outside edge for the
connector housing. Gently remove the
fiber optic insert from the connector.
(Figure B)
• From the MOST Interface: Push the
tab toward the dust cover and, using
a needle nose plier, remove the dust
cover. Replace the connector with the
factory fiber optic cables into the MOST
interface’s black connector housing.
(Figure C)
(Figure A)
(Figure B)
(Figure C)
