9
REV. 11/22/24 INSTAXDIS-HK4
STEERING WHEEL CONTROL SETTINGS
(CONT.)
Continued on the next page
Note: Some radios may not have these commands. Please refer to the manual provided with the
radio, or contact the radio Manufacturer for specific commands recognized by that particular radio.
* Not applicable in this application
Remapping the Steering Wheel Control Buttons
Once the AXDIS-HK4 interface has been programmed, the button assignment for the steering
wheel controls may be reassigned if so desired. For example, if Seek Up is preferred to be Mute
instead. Follow the steps below to remap the steering wheel control buttons.
1. Ensure that the AXDIS-HK4 interface is visible so you can see the LED flashes to confirm
button recognition.
Tip: Turning the radio off is recommended.
2. Within the first twenty seconds of turning the ignition on, press and hold the Volume Up
button on the steering wheel until the LED goes solid.
3. Release the Volume Up button, the LED will then go out. The Volume Up button has now
been programmed.
4. Follow the list in the Button Assignment Legend to reference the order in which the
steering wheel control buttons need to be programmed.
Note: If the next function on the list is not present on the steering wheel, press the Volume Up
button for (1) second until the LED comes on to skip that function, then release the Volume Up
button. This will tell the AXDIS-HK4 interface that this function is not available, and to move on
to the next function.
5. To complete the remapping process, press and hold the Volume Up button until the LED in
the AXDIS-HK4 interface goes out.
1. Volume-Up
2. Volume-Down
3. Seek-Up/Next
4. Seek-Down/Prev
5. Source/Mode
6. Mute
7. Preset-Up
8. Preset-Down
9. Power
10. Band
11. Play/Enter
12. PTT (Push to Talk)
13. On-Hook
14. Off-Hook
15. Fan-Up *
16. Fan-Down *
17. Temp-Up *
18. Temp-Down *
Button Assignment Legend
