AXDIS-GM13
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 11/1/24 INSTAXDIS-GM13
INTERFACE FEATURES
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink • Tape
• Wire cutter • Zip-ties
TABLE OF CONTENTS
Connections ........................................................ 2-3
Installation .............................................................3
Programming the AXDIS-GM13 ............................. 4
Adjusting the AXDIS-GM13 ....................................4
Steering Wheel Control Settings (SWC)........... 5-7
- LED Feedback .......................................................5
- Changing Radio Type ..........................................5
- Remapping SWC Buttons ...................................6
- Dual Assignment Instructions ............................7
Troubleshooting.....................................................8
GM Data Interface with SWC 2005-2011
• Designed for amplified models
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains audio controls on the steering wheel
• Retains OnStar
®
• Retains balance and fade
• Micro-B USB updatable
INTERFACE COMPONENTS
• AXDIS-GM13 interface
• AXDIS-GM13 harness
• 16-pin harness
• 3.5mm adapter
CADILLAC
STS .............................................................. 2005-2011
Visit AxxessInterfaces.com for up-to-date
vehicle specific applications.
ATTENTION: With the key out of the
ignition, disconnect the negative battery
terminal before installing this product. Ensure
that all installation connections, especially the
air bag indicator lights, are plugged in before
reconnecting the battery or cycling the ignition
to test this product.
NOTE: Refer also to the instructions included
with the aftermarket radio.
Product Info
www.MetraOnline.com
MetraOnline.com may be used
to assist with dash assembly
instructions. Simply enter
your Year, Make, Model
vehicle into the vehicle fit
guide and look for the Dash
Kit Installation Instructions.
