6
PROGRAMMING THE AXDIS-CL2 (CONT)
6. Once the vehicle has been auto detected by the interface, the LED will turn on solid
Green, and the radio will come back on, indicating programming was successful.
7. Immediately after the radio comes back on, the following buttons on the steering wheel
must be pressed in the exact sequence as shown. For each button press, the LED will turn
on momentarily. If a button is not present, press Volume-Up to skip that button.
8. The LED will turn on after the last Volume-Up button has been pressed, indicating
programming has ended.
9. Test all functions of the installation for proper operation, before reassembling the dash.
10.
If the interface fails to function, refer to Resetting the AXDIS-CL2, then resume from step 7.
Notes:
• PTT (OnStar
®
) when pressed will Mute/Attenuate the radio.
• PTT (OnStar
®
) when pressed and held for 2 seconds will activate OnStar
®
, if applicable.
• Volume Up • Seek Up • Volume Up • PTT (OnStar
®
) or MUTE • Volume Up
For all other applications:
For the steps below, the LED located inside the interface can only be seen while active. The
interface does not need to be opened to see the LED
1. Start the vehicle.
2. Connect the AXDIS-CL2 harness to the wiring harness in the vehicle.
3. The LED will initially turn on solid Green, then turn off for a few seconds while it auto
detects the radio installed.
4. The LED will then flash Red up to (26) times indicating which radio is connected to the
interface, and then turn off for a couple of seconds. Pay close attention to how many Red
flashes there are. This will help in troubleshooting, if need be. Refer to the LED feedback
section for more information.
5. After a couple seconds the LED will turn on solid Red while the interface auto detects the
vehicle. The radio will shut off at this point. This process should take 5 to 30 seconds.
6. Once the vehicle has been auto detected by the interface, the LED will turn on solid
Green, and the radio will come back on, indicating programming was successful.
7. Test all functions of the installation for proper operation, before reassembling the dash.
8. If the interface fails to function, refer to Resetting the AXDIS-CL2.
Note:
The LED will turn on solid Green for a moment, and then turn off under normal operation after
the key has been cycled.
