2
APPLICATIONS CONNECTIONS
From the AXDI-CL2 harness to the aftermarket radio, connect the:
• Black wire to the ground wire.
• Yellow wire to the battery wire.
• Red wire to the accessory wire.
• Blue/White wire to the amp turn-on wire.
• Orange wire to the illumination wire (if applicable).
Note: There are (2) illumination wires. If the Orange wire on the 24-pin harness is populated
on the factory side, use that wire instead.
• Tape off and disregard the Orange/White wire, it will not be used in this application.
• Gray wire to the front right positive speaker output.
• Gray/Black wire to the front right negative speaker output.
• White wire to the front left positive speaker output.
• White/Black wire to the front left negative speaker output.
• Green wire to the rear left positive speaker output.
• Green/Black wire to the rear left negative speaker output.
• Purple wire to the rear right positive speaker output.
• Purple/Black wire to the rear right negative speaker output.
The following (3) wires are only for multimedia/navigation radios that require these wires.
• Blue/Pink wire to the VSS/speed sense wire.
• Green/Purple wire to the reverse wire.
• Light Green wire to the parking brake wire.
BUICK
Century 2004-2005
LaCrosse 2005-2009
Rainier * 2004-2007
Regal 2004
Rendezvous 2002-2007
Terraza 2005-2007
CADILLAC
Escalade, Escalade ESV & EXT †
2003-2006
CHEVROLET
Avalanche ** 2003-2006
Cavalier 2000-2005
Colorado 2004-2012
Corvette 2005-2013
Express 2003-2007
Impala 2000-2005
Kodiak C4500-C8500 2003-2009
Malibu 2001-2003
Malibu Classic 2004-2005
Monte Carlo 2000-2005
CHEVROLET (CONT)
Silverado ** 2003-2006
Silverado Classic ** 2007
SSR * 2003-2006
Suburban ** 2003-2006
Tahoe ** 2003-2006
Trailblazer * 2002-2006
Trailblazer 2007-2009
Uplander 2005-2008
GMC
Canyon 2004-2012
Envoy * 2002-2006
Envoy 2007-2009
Savana 2003-2007
Sierra ** 2003-2006
Sierra Classic ** 2007
TopKick C4500-C8500 2005-2009
Yukon / Yukon XL ** 2003-2006
HUMMER
H2 † 2003-2007
H3/H3t 2006-2010
ISUZU
Ascender 2003-2008
H-Series 2003-2008
I-Series 2006-2008
OLDSMOBILE
Alero 2001-2004
Bravada 2002-2004
Intrigue 2002
PONTIAC
Aztec 2001-2005
Grand Am 2001-2005
Grand Prix 2004-2008
Montana SV6 2005-2006
Sunfire 2000-2005
SAAB
9-7x 2005-2009
SATURN
Relay 2005-2007
* These vehicles have a digital amplifier option. Please reference the “Service Parts Identification” sticker
located in the glove box for the RPO code UQA. If UQA is present, then the vehicle is equipped with a digital
amplifier. Either use the AXDIS-CL2 interface, or bypass the amplifier.
** These vehicles have a digital amplifier option. Please reference the “Service Parts Identification” sticker
located in the glove box for the RPO code Y91. If Y91 is present, then the vehicle is equipped with a digital
amplifier. Either use the AXDIS-CL2 interface, or bypass the amplifier.
†
These vehicles are standard for a digital amplifier. Either use the AXDIS-CL2 interface, or bypass the amp
.
