8
GAIN SETUP
7. Using a Digital multi-meter set to Volts AC, touch the Black lead to the OUTPUT RCA shield
and insert the Red lead to the center of the RCA OUTPUT. You will see a voltage reading
show on the multi-meters screen.
8. Adjust the OUTPUT LEVEL of the LOC until the voltage shown on the screen matches the Line
Input Maximum Sensitivity of the aftermarket amplifier. If the Maximized light comes on
before the level is reached reduce OUTPUT LEVEL until the light is off.
9. Repeat steps 7 and 8 for the rear output.
10. Press the Bass Enhancement Knob making sure the LED is lit. Bass Enhancement is engaged.
An RTA and Pink noise generator is recommended. If using vehicle source, reduce radio volume
reconnect RCAs and play– pink noise.
11. Turn EFFECT gain to half.
12. Adjust FREQ. to the expected center of your sub frequency range, between 30hz -80hz.
13. Adjust Subsonic Filter just below the sub boxes tuning frequency
14. Cycle the WIDTH from Narrow to Wide. Narrow will effect a small range of frequencies, Wide
will effect a larger range of frequencies.
15.
Adjust EFFECT gain increasing the output of the frequencies effected by the Width adjustment.
16. Further on the fly adjustment of the Effect can be made by using the outside ring of the
bass knob.
17. Push Bass Knob to turn on and off to test.
18. Turn the radio’s volume down.
19. Connect the RCAs from aftermarket amplifier to the LOC.
20. Adjust the gain on your amplifier(s) to minimum.
21. Refer to the amplifiers manual if additional adjustments are required.
NOTE: If at any point during the adjustments of the Enhancement circuit the Maximized
LED lights up simply reduce the gain adjustment on the AX-BRC-PRO until it is no longer lit.
