MXNET 1G USER MANUAL

•

Connects to a variety of devices including control CPUs, DSPs, and the

MXNet network switches, AC-MXNET-SW10, AC-MXNET-SW24, and

AC-MXNET-SS48

NOTE: For advanced network data tracking, one of Ports 2-7 must be

directly connected to the MGMT port on the network switch (applies only to

the AC-MXNET-SW24 and AC-MXNET-SW48). Connect any of Ports 2-7 to

the MGMT port on the MXNet network switch to track switch performance

and data usage with the Mentor web UI.

10

MXNET (PoE)

AV NETWORK

•

8-pin RJ-45 female connector port

• Supports standard PoE power, IEEE 802.3AF (15.4 W)

• Connects to any 1GbE port on the MXNet network switch to provide

PoE to the CBOX and Mentor control connection to the encoders and

decoders

11

RS232

•

3-pin terminal block connector port

• System control port for MXNet using RS-232

• Default Baudrate is 115200

12

[Optional]

POWER

•

DC 12V/1A locking ring power charger to locally power the CBOX

• Not required when connecting the CBOX to a network switch that

provides PoE
