MXNET 1G USER MANUAL

10

USB 2

•

USB 2.0 Type A female connector port

• Supports routing USB 2.0 signals from the decoder to the designated host

encoder

NOTE: Chipset V1 Decoders do not support High-speed USB connections. Chipset

V2 Decoders can support one isochronous connection to a High-speed USB device

(such as a microphone or digital camera).

11

USB SELECT

•

FPGA/MCU toggle switch

• Used for configuring the decoder for point-to-point connection with an

MXNet 1G encoder (default setting is MCU ISP)

12

USB

•

Micro-USB Type B female connector port

• Used for configuring the decoder for point-to-point connection with an

MXNet 1G encoder

13

1GbE NETWORK

•

8-pin RJ-45 female connector, 1000BASE-T copper Ethernet port

• Supports standard PoE power, IEEE 802.3AF (15.4 W)

• Maximum power consumption of 6.5 W

• 10/100/1000Mbps auto-negotiation

• MDI/MDI-X cable mode auto-negotiation

• Maximum distance 100m (330ft) over Cat5e and higher

14

BI DIR. O.M. LC

FIBER

•

Bidirectional SFP fiber optic connector port

• Supports single mode or multimode SFP modules for extremely long runs

• Recommended single mode fiber: LC to LC 1310nm, up to 40km (24.85 miles)

• Recommended multimode fiber: LC to LC 850nm, up to 550m (1804 feet)

15

HDMI OUT

•

19-pin HDMI Type A female connector port

• HDMI connection for endpoint device signal output

• Copy EDID functionality used in conjunction with front panel button press

16

AUDIO OUT

•

3.5mm stereo jack (TRS) audio output port

• De-embedded audio, extracts stereo analog audio

17

RESET

•

Recessed button, use a paperclip or pen to press in and hold for 7 seconds to

restore decoder to factory default settings

18

[Optional]

POWER

•

DC 12V/1A locking ring power charger to locally power decoder

• Not required when connecting decoder to a network switch that provides PoE
