27
en
5. Use cases
To use AISA in combination with the AMI, the last RCA output of an Audiotec Fischer DSP product must be connected
to the Line input (R) of the AMI (page 21, point 7). Then, set the Line input voltage switch (page 21, point 6) to 1 V.
Connect the AMI to your PC via the USB-C port using the included USB-C cable.
Note: When using DSP PC-Tool 5, ensure that the right Line Input of the AMI is selected in the AISA settings before
starting the measurement.
To do this, navigate to the IO tab, open the Advanced Input Signal Analyzer by clicking on the icon, and then click
the icon.
In the following we show you the applications of the AUDIO MEASUREMENT INTERFACE using the DSP PC-Tool 6
software as an example.
5.1 Using the Advanced Input Signal Analyzer (AISA) to correct the input signal from an OEM head unit
DSP /
DSP amplier
PC
Last
3 m USB-C to USB-C
cable with USB-A adaptor
USB-C
USB-C
USB-A
or
3,5 m mono
RCA cable
1
2
4
3
5
switch:
1V
