www.audibax.com 43
M88 DSP / M88 DSP Dante
byte5
Control
Type
byte6
Data
Length
byte7
Reserved
byte8
Reserved
byte9
GPIO
Direction
byte10
Start GPIO
byte11
End GPIO
byte12
Value
byte5
Input/Output
byte6
Start Channel
byte7
End Channel
byte8
Parameter Type
byte9-72
Parameter Value
V2:
- Message types (byte2): There are three message types (byte2) including 0x21 （
parameter controls）, 0x22（parameter acquisition）, 0x13（scenario switch）, 0x74（other
controls） and 0x6e（Dante routing.
- Length (byte3): Fill in corresponding data section length based on information type. The
length can be longer when actual sending is carried out. Total data volume can be got
through adding 4 byte header information to data length.
1. Parameter Control (0x21)
At this point, the formats of data section are as follows
byte5: It indicate control input or output channel, 0x2- input channels and 0x1-output
channels
byte6-7: They indicate start and end channel numbers. Channel numbers start from 0.
byte8: This kind of parameter is the same with V1 version. Please refer to Appendix B.
byte9-40: Fill in parameter values of start to end channels. It shall be filled in from the
ninth byte.
Each parameter value shall take two bytes.
2. Parameter Acquisition (0x22)
Data section format is the same with parameter controls. Parameter values may not be
filled in. acquired parameters will be filled in this position.
3. Scenario Switch (0x13)
byte5: Fill in scenario numbers (0-15).
byte6-8: Fill in 0.
4. Other Controls (0x74)
Other controls include but not limited to GPIO, RS232, RS485 and central control replies.
The protocol formats are as follows.
GPIO:
