www.audibax.com 44
M88 DSP / M88 DSP Dante
byte5
Control Type
byte6
Data Length
byte7
Reserved
byte8
Reserved
byte9-132
Data
byte5
Control Type
byte6
Data Length
byte7
Reserved
byte8
Reserved
byte9
Reply Switch
byte5
Dante
Channel No.
byte6
Routing
Switch
byte7
Reserved
byte8
Reserved
byte9-24
Subscribed
channel name
byte24-40
Suscribed
device name
The controlling type for byte5 is 1.
The data length of byte6 is fixed as four bytes.
Byte9 GPIO direction, set input or output. Value 0 indicates input, and value 1 indicates
output.
Byte10-11 start GPIO and end GPIO. DSP devices totally have eight GPIOs, which are
indicated with number 0-7.
Byte12 is determined according to byte9GPIO direction. The field shall be filled in high (1)
/low (0) level for output settings. The field is a return field to read GPIO level value on
devices for input settings.
RS232/RS485:
Byte5 is 2 when controlling type RS232, and 3 for RS485.
The data length of byte6 refers to data length that shall be sent via RS232/485 currently.
Byte9-132 shall be filled in data sent by RS232/485.
Central control replies:
Byte5 controlling type is 4.
The data length of byte6 is 1.
When byte9 is 1, it means turning on central control replies switch; and 0 means turning
off replies.
5. Dante Routing (0x6e)
Data section formats are:
Byte5 Dante channel numbers. The difference is, Dante channel numbers start from 1.
Byte6 Dante channel, subscribe/cancel subscription of appointed channels of Dante
devices indicated with byte25-49. The appointed channels are indicated with byte9-24
channel names.
