www.audibax.com 42
M88 DSP / M88 DSP Dante
Software coding rules (total 12 bytes)
V1:
- Information types (byte2): There are three information types including 0x21 (parameter
controls), 0x22 (parameter acquisition) and 0x13 (scenario switch).
- Length (byte3): invalid.
- 0x21 (parameter control):
At this point, Databyte5~12 are respectively
Please refer to Appendix A to get the distribution of Module ID (byte5~6).
Please refer to Appendix B for Parameter types (byte7~8).
When Parameter 1 (byte9~10) has only one parameter, then only parameter 1 is valid, such
as control compressor switch.
Parameter 2 (byte11~12) only valid when there are two parameters, such as control output
channel 1 mute. Parameter value 1 shall be filled in input channel number from 0.
Parameter value 2 shall be filled in 1 (mute).
- Exception: Matrix routing has three parameters. The first one is input channel number,
the second one is output channel number, and the third one is routing switch. At this
point, byte9 of parameter value 1 shall be filled in input channel numbers, byte 10 shall be
filled in output channel number, and parameter 2 shall be filled in routing switch.
- 0x22 (Parameter Acquisition):
Parameter acquisition rules are the same with parameter controls. The difference
between them is values acquired shall be filled in parameter 1 and parameter 2
0x13 (Scenario Switch):
Users only need to fill scenario numbers (0~15) in byte5 and 0 in byte6~12.
Note: Central control command of V1 version can acquire code through software menu
bar of PC. For customized development, please use this protocol rule
byte1
0xb3
byte2
Message
byte3
Length
byte4
Version
byte5-6
Module ID
byte7-8
Parameter Type
byte9-10
Parameter 1
byte11-12
Parameter 2
Type No.
byte5-132
Data
