AT-UHD-HDVS-300-KIT
20
Basic Operation
Figure 1.2 - HDMI 2 is selected as the active video input and Laptop 2 has access to the mouse, keyboard, and
camera. For purposes of clarity, the HDBaseT connection between the transmitter and receiver is not shown.
Black signal lines indicate that the AT-UHD-HDVS-300 is not switched to that input.
USB
USB
USB
HDMI IN 5
USB HUB HDBaseT IN USB 3 DC 48V
+
USB 2USB 1 AUDIO VGA IN DP IN 4
USB HUB HDBaseT OUT RS-232
RX TX
LAN
HDMI IN 2
HDMI IN 1
USB
USB
HDMI Out
USB 1
USB
USB
USB
USB 2
HDMI In 2
HDMI In 5
Laptop 1
HDMI In 1
Laptop 2
Display
Mouse
Keyboard
USB Camera
Media Player
4
media4
Laptop 1
Laptop 2
Laptop 2
8. Press the INPUT button on the front panel and select HDMI 2. When HDMI 1 is selected, USB 1 will be the
active USB host and will have access to all connected USB devices on the transmitter and receiver.
USB 2USB 1 AUDIO VGA IN DP IN 4
USB HUB HDBaseT OUT RS-232
RX TX
LAN
HDMI IN 2
HDMI IN 1
USB
USB
AT-UHD-HDVS-300-TX
HDMI 1
POWER INPUTV
V
HDMI 2
VGA
DP
HDMI - RX
Input LED indicator
