AT-UHD-HDVS-300-KIT
19
Basic Operation
USB
USB
USB
HDMI IN 5
USB HUB HDBaseT IN USB 3 DC 48V
+
USB 2USB 1 AUDIO VGA IN DP IN 4
USB HUB HDBaseT OUT RS-232
RX TX
LAN
HDMI IN 2
HDMI IN 1
USB
USB
HDMI Out
USB 1
USB
USB
USB
USB 2
HDMI In 2
HDMI In 5
Laptop 1
HDMI In 1
Laptop 2
Display
Mouse
Keyboard
USB Camera
Media Player
4
media4
Laptop 1
Laptop 1
Laptop 2
Figure 1.1 - HDMI 1 is selected as the active video input and Laptop 1 has access to the mouse, keyboard, and
camera. For purposes of clarity, the HDBaseT connection between the transmitter and receiver is not shown.
Black signal lines indicate that the AT-UHD-HDVS-300 is not switched to that input.
