AT-UHD-CAT-2
25
Device Operation
Power Button Modes
The main function of the POWER button on the front panel is to toggle the AT-UHD-CAT-2 between standby and
normal operating mode. This is the default mode. However, this button can also be dened to send CEC power-
on and power-o commands, over HDBaseT, to the display (sink) devices. It can also be dened to simultaneously
power-on or power-o the AT-UHD-CAT-2 and any connected displays.
Normal Operation
By default, pressing the POWER button will toggle the power state of the AT-UHD-CAT-2. When the unit is in normal
operating mode, the POWER button will be blue. Pressing the POWER button again, will place the unit into standby
mode, and the POWER button will be red. In standby mode, no video signal will pass to the display (sink) device.
However, TCP/IP access to the unit will be maintained, allowing access to the web server and Telnet sessions.
1. Launch a web browser and login to the web server. Refer to Introduction to the Web Server (page 29) for more
information. The factory-default username and password are listed below:
Username: root
Password: Atlona
2. Click System in the menu bar.
3. Click the Power button mode drop-down list and select DA standby. Pressing the POWER button on the
front panel will toggle between power-on and standby modes on the AT-UHD-CAT-2. Connected display (sink)
devices will not receive CEC power-on / power-o messages.
