Using OmniStream
™
with Velocity
™
Device Manager
27
• Very that all encoders and decoders are set to the same system mode. In this tutorial, both encoders and the
decoder should be set to VCx. Refer to Setting the System Mode (page 16).
• Go to the INPUT menu and verify the folllowing. Refer to Conguring Inputs (page 17) for more information.
» Make sure that the Cable Present indicator, under the HDMI Input 1 window group, is green.
» Make sure the Input drop-down list is assigned to an input. In this tutorial, the Input eld for both encoder 1
and encoder 2 are set to HDMI Input 1.
» Verify that the Max bit rate eld is set to at least 450.
» Verify that a Thumbnail > Enable toggle switch is enabled and a thumbnail of the source is displayed. When
enabled, the toggle switch will be green.
• Go to the SESSION menu and verify the following under the Stream 1 window group. Refer to Creating a
Session (page 20) for more information.
» Make sure the Interface eld for both encoders is set to eth1.
» Verify that the Encoder eld is set to Encoder 1.
» Check that the Scrambling toggle switch is enabled (green). Also check that the Key eld, for this example,
is set to scrambling for both encoders.
» Verify that the Video > Video Enable toggle switch is set to enabled for both encoders.
» Check the Video > Destination Multicast/Unicast Address eld is set to the correct multicast IP address.
In the example, 226.0.0.1. is used on encoder 1 and 226.0.0.2 is used on encoder 2.
» Check that the Video > Destination UDP Port eld is set to the proper port. In this example, 1000 should
be used on both encoders.
» Make sure the Audio > Source is set to HDMI 1 on both encoders.
» Verify that the Audio > Enable Audio toggle switch is enabled on both encoders.
» Check the Audio > Destination Multicast/Unicast Address eld is set to the correct multicast IP address.
In this example, 226.0.10.1 is used on encoder 1 and 226.0.10.2 is used on encoder 2.
» Check that the Audio > Destination UDP Port eld is set to the proper port. In this example, 1100 is used
for both encoders.
If no video and/or audio is present on the display, check the following:
Encoder Checklist
Basic Conguration Tutorial
Troubleshooting
