Using OmniStream
™
with Velocity
™
Device Manager
28
Basic Conguration Tutorial
• Very that all encoders and decoders are set to the same system mode. In this tutorial, both encoders and the
decoder should be set to VCx. Refer to Setting the System Mode (page 16).
• Go to the IP INPUT menu and verify the following. Refer to Subscribing to an Encoder (page 22) for more
information.
» Under both the IP Input 1 and IP Input 2 window groups, verify that the Enabled toggle switch is enabled
(green).
» Check that the Multicast Address eld is set to the correct multicast IP address. In this example,
226.0.0.1 for IP Input 1 and 226.0.0.2 for IP Input 2.
» Check that the Port eld is set to the proper port. In this example, 1000 for both IP Input 1 and IP Input 2.
» Under both the IP Input 3 and IP Input 4 windows groups, verify that the Enabled toggle switch is enabled
(green).
» Check that the Multicast Address eld is set to the correct multicast IP address. In this example,
226.0.10.1 for IP Input 3 and 226.0.10.2 for IP Input 4.
» Check that the Port eld is set to the proper port. In this example, 1100 for both IP Input 3 and IP Input 4.
• Go to the HDMI OUTPUT menu and verify the following. Refer to Subscribing to an Encoder (page 22) for
more information.
» Make sure that the Descrambling > Enabled toggle switch is enabled (green).
» Verify that the Descrambling > Key eld matches the Scrambling > Key eld in the encoder. For this
tutorial, both of these elds should be set to scrambling.
IMPORTANT: The scrambling key on a decoder must be identical to the scrambling key on the
encoder which is being subscribed. Scrambling keys are case-sensitive.
Decoder Checklist
» Check the HDCP > Supported Version eld to make sure the correct version is selected. Also note the
color of the HDCP > Encrypted indicator. If it is red, then a picture may not be displayed and result in a
“blue screen” on the display. Change the HDCP > Supported Version eld, if necessary.
» Make sure that the Video > Video drop-down list is set to one of the congured video inputs: either IP
Input 1 - 226.0.0.1:1000 | 10.1.0.111 or Input 1 - 226.0.0.2:1000 | 10.1.0.116.
» Make sure that the Audio > Input drop-down list is set to one of the congured inputs: either IP Input 3
- 226.0.10.1:1000 | 10.1.0.111 or Input 4 - 226.0.10.2:1000 | 10.1.0.116.
