5
Installation Guide
AT-HDR-EX-100CEA-TX
Refer to the tables below for recommended cabling when using Altona products with HDBaseT.
The green bars indicate the signal quality when using each type of cable. Higher-quality signals
are represented by more bars.
Cable Recommendation Guidelines
Core Shielding CAT5e CAT6 CAT6a CAT7
Solid UTP (unshielded) N/A
STP (shielded)
*Atlona recommends TIA/EIA 568-B termination for optimal performance.
Cable* Max. Distance @ 4K Max. Distance @ 1080p
CAT5e 295 feet (90 meters) 330 feet (100 meters)
CAT6 / CAT6a / CAT7 330 feet (100 meters) 330 feet (100 meters)
IMPORTANT: Stranded or patch cables are not recommended due to
performance issues.
1. Connect an AV source to the HDMI IN port on the transmitter.
2. Connect a display to the HDMI OUT port on the compatible receiver.
3. Connect an RJ45 cable, from the HDBaseT OUT port on the transmitter, to the HDBaseT
input of a compatible receiver.
4. Connect an Ethernet cable from the LAN port to a network switch or source (when receiving
Ethernet from the compatible receiver).
5. *Optional* Connect an RS-232 control system to the transmitter or connect an RS-232
source to be controlled by the compatible receiver’s RS-232.
6. *Optional* Connect an IR emitter to the TX and ground port. Connect an IR receiver to the
RX and ground port.
7. Connect the included 48 V DC power supply to the DC 48V port on the transmitter.
8. Connect the power supply to an available AC outlet.
Installation
