25
Figure 10: Shows the location of the BIOS Security Jumper. The Pins1&2 and Pins 2&3 jumpers
determine the BIOS Security program’s mode.
Top view
Pins 1&2: jumper position forNormal mode
Pins 2&3: jumper position for Lockdownmode
No jumper: Recovery mode
Figure 10. BIOS Security Jumper Header
Table 21 describes the jumper settings for the three modes: normal, lockdown, and configuration.
Table 20. BIOS Security Jumper Settings
Function/Mode
Jumper Setting
Configuration
Normal
1-2
The BIOS uses current configuration information and passwords for
booting.
Lockdown
2-3
The BIOS uses current configuration information and passwords for
booting, except:
•
All POST Hotkeys are suppressed (prompts are not displayed and keys
are not accepted. For example, F2 for Setup, F10 for the Boot Menu).
•
Power Button Menu is not available (see Section 3.6.3.2 Power Button
Menu).
BIOS updates are not available except for automatic Recovery due to flash
corruption.
Configuration
None
BIOS Recovery Update process if a matching *.bio file is found. Recovery
Update can be cancelled by pressing the Esc key.
If the Recovery Update was cancelled or a matching *.bio file was not found,
a Config Menu is displayed. The Config Menu consists of the following
(followed by the Power Button Menu selections):
[1]
Suppress this menu until the BIOS Security Jumper is replaced.
[2]
Clear BIOS User and Supervisor Passwords.
[3]
Reset ASUS AMT to default factory settings.
[F2] ASUS Visual BIOS.
[F4]
BIOS Recovery.
See Section 4.3.2 Power Button Menu
NOTE The ASUS NUC Rugged NUC13BR Boards and Kits do not support discrete TPM.
