T12 Tube Mic Preamp API Select
5
3.0 Overview
The T12 Mic Preamp provides a comprehensive suite of controls:
• HI-Z IN: High-impedance, 500kW, unbalanced ¼” instrument input
• MIC IMPEDANCE: Sets the impedance of the microphone input
o Four fixed impedance choices: 500, 1500, 2000, and 2500 OHMS
• LOW CUT: Sets the cut-off frequency of the high-pass filter
o Four filter choices: OUT, 60, 120, and 240 HZ (Hertz)
• GAIN: Sets the amount of gain applied to the input signal
• LEVEL: Trims the level of the output stage
• POL (Polarity): Toggles to activate the input polarity inverter
• 48V: Toggles to apply 48-volt phantom power to the microphone INPUT
• PAD: -20dB input pad (applies to both MIC and HI-Z inputs)
• MIC: Toggles between the MIC and HI-Z inputs
• PEAK: +18dBu LED peak indicator
• OUTPUT LEVEL VU: Back-lit, vintage look output VU meter
