T12 Tube Mic Preamp API Select
6
4.0 Preamp Controls
Each channel of the T12 Mic Preamp is equipped with a comprehensive set of parameters and features.
4.1 Microphone Input Impedance
MIC IMPEDANCE OHMS: Selects the impedance of the microphone INPUT
• 4 impedance choices: 500, 1500, 2000, and 2500 OHMS
• 1500 OHMS is a nominal setting*
*NOTE: To obtain optimal frequency response from most microphones, MIC
IMPEDANCE should be set to around 10 times the microphone’s
output impedance.
4.2 Low Cut Filter
LOW CUT: Selects the function of the high-pass filter
• 4 filter choices: OUT (no filter), 60, 120, and 240 HZ
• Gentle first-order (6dB/8va) filter
4.3 Preamp Gain
GAIN: Sets the amount of gain the preamp applies to the input signal
• +20dB to +70dB range
• 11-step detented control
4.4 Output Trim
LEVEL: Trims (attenuates) the level of the output stage
• Post preamp and pre tube output stage
• Unity gain is at the fully clock-wise position
• Output level can be trimmed downward from the unity gain position
• 0dB to -5dB range
• 0.5dB steps
• 11-step detented control
