9
ANGENIEUX OPTIMO ULTRA COMPACT WIDE ANGLE
CONFIGURATION
FF/VV
CONFIGURATION
U35
Zoom ratio
2.7x
2.7x
Focale Length (mm)
21-56
16-42
Maximum aperture
T2.9
T2.2
Minimum Object Distance (ft)/(m)
2' / 0.6m
2' / 0.6m
Image coverage (mm)
46.3
34.6
Weight (kg / lbs)
2.8 / 6.17
2.8 / 6.17
Front diameter (mm)
114
114
Max diameter (mm)
114
114
Length (front to mount) (mm)
247 / 9 23/32 in
247 / 9 23/32 in
Mounts
PL
PL
Internal focus
Yes
Yes
Iris scales 2 opposite scales
2 opposite scales
2 opposite scales
Angular rotation of iris ring (°)
71.4°
71.4°
Iris gear drive
126 teeth, pitch 32
126 teeth, pitch 32
Zoom scales
2 opposite scales
2 opposite scales
Angular rotation of zoom ring (°)
150°
150°
Zoom gear drive
126 teeth, pitch 32
126 teeth, pitch 32
Focus scales
metric or footage
marked
metric or footage marked
Angular rotation of focus ring (°)
310°
310°
Focus gear drive
126 teeth, pitch 32
126 teeth, pitch 32
Angular Field of View
Focal Length
21-56
16-42
Horizontal angular field of view
87.5° / 40.2°
87.5° / 40.2°
Object dimensions at MOD (mm)
688 x 352 / 260 x 140
682 x 340 / 258 x 136
(for Full-Frame :
40.96x21.6mm)
(for U35 :
30.7x15.8mm)
